Laminated safety glass

Designations	Nominal thickness (mm)	Light transmission level (%)	Degree of light reflection(%)	g-value (%)	U-value (W/m²K)
22.1	4	91	8	84	5.5
22.2	4	91	8	83	5.4
33.1	6	90	8	82	5.4
33.2	6	90	8	81	5.4
33.4	7	90	8	80	5.2
44.1	8	90	8	81	5.4
44.2	8	90	8	80	5.3
44.4	9	90	8	79	5.2
55.1	10	89	8	79	5.3
55.2	10	89	8	78	5.2
44.6	10	90	8	78	5.1
55.4	11	89	8	77	5.1
66.1	12	89	8	78	5.2
66.2	12	89	8	77	5.2
55.6	12	89	8	76	5.0
66.4	13	89	8	76	5.1
66.6	14	89	8	75	5.0
88.2	16	88	8	75	5.1
88.4	17	88	8	73	5.0
88.6	18	88	8	73	4.9
1010.2	20	87	8	72	5.0
1010.4	21	87	8	71	4.9
1010.6	22	87	8	70	4.8
1212.2	24	86	8	70	4.9
1212.4	25	86	8	69	4.8
1212.6	26	86	8	68	4.7
1515.4	31	85	8	66	4.7
1515.6	32	85	8	66	4.6
1919.4	39	83	8	63	4.5
1919.6	40	83	8	62	4.4

Radiophysical data

Designations	Nominal thickness (mm)	Light transmission level (%)	Degree of light reflection(%)	g-value (%)	U-value (W/m²K)
22.1	4	91	8	86	55
22.2	4	91	8	85	5.4
33.1	6	91	8	86	5.4
33.2	6	91	8	85	5.4
33.4	7	91	8	83	5.2
44.1	8	91	8	85	5.4
44.2	8	91	8	84	5.3
44.4	9	91	8	83	5.2
55.1	10	91	8	85	5.3
55.2	10	91	8	84	5.2
44.6	10	91	8	82	5.1
55.4	11	91	8	83	5.1
66.1	12	91	8	85	5.2
66.2	12	91	8	84	5.2
55.6	12	91	8	82	5.0
66.4	13	91	8	82	5.1
66.6	14	91	8	81	5.0
88.2	16	91	8	83	5.1
88.4	17	91	8	82	5.0
88.6	18	91	8	81	4.9
1010.2	20	91	8	82	5.0
1010.4	21	91	8	81	4.9
1010.6	22	91	8	80	4.8
1212.2	24	90	8	82	4.9
1212.4	25	90	8	80	4.8
1212.6	26	90	8	79	4.7
1515.4	31	90	8	79	4.7
1515.6	32	90	8	79	4.6
1919.4	39	90	8	78	4.5
1919.6	40	90	8	77	4.4

Date table Laminated safety glass made of float glass (EUROFLOAT)
